18 Orchestral selections An ideal organ for church or concert

The Inspire Series 343 has a total of 233 stops spread of 43 illuminated stop tabs, a variant library and 18 orchestral selections. Equipped with three velocity-sensitive manuals, a 32-note ago pedal board and an internal 2.1 audio system with the option of expanding to a 6.2 plus 2-channel antiphonal external audio system, the Inspire Series 343 is a state-of-the-art church and concert organ with unending flexibility.

Orchestral selections

FOUR ORGAN STYLES

In addition to the standard stoplist - American Eclectic - stops can be selected from the English Cathedral, French Romantic and German Baroque styles. The Variant Library consists of extra stops to choose as desired. The organist is not limited to stops from only one style; all are available instantly. For those who appreciate a large variety of sounds the Inspire Series 343 is an ideal choice.


ANTIPHONAL SWITCHING

A particularly convenient feature of the Inspire Series 343 is antiphonal switching. This enables the organ to support congregational worship in large spaces where the congregation may be at some physical distance from the main organ's sound. For musical effects, the organist can transfer the organ sound with the push of a button for multi-directional sound, or sound from only the rear or the front of the worship space.

Specifications

Inspire Series 343

Voices

43 stops / 233 total voices

4 unique organ styles + Variant Library

215 Voice Palette™ voices

18 orchestral voices

Keyboards

Velocity-sensitive “Pipe Organ Feel” tracker touch keyboards

Pedalboard

Velocity-sensitive 32-note AGO pedalboard

General Pistons

10

Toe Pistons

10 (4 more optional)

Divisional Pistons

5 Great, 5 Swell, 5 Choir, 5 Pedal

Couplers

6 (Great to Pedal, Swell to Pedal, Choir to Pedal, Swell to Great, Choir to Great, Swell to Choir)

8 Orchestral Couplers (2 x Great, 2 x Swell, 2 x Choir, 2 x Pedal)

Bass Coupler

2 Melody Couplers

Tremulants

3 (Great, Swell, Choir)

Shoes

Great, Choir, Pedal expression

Swell expression

Crescendo

Memory

50 levels x 30 pistons (1500)

Console Dimensions

Height: 49” (124.5 cm)

Width: 60.0” (152.4 cm)

Depth: 29.9” (75.9 cm)

Depth with pedalboard: 46.5” (118.1 cm)

AVAILABLE COLORS:

Dark

Oak

Medium

Oak

Light

Oak

Features

Inspire Series 343

  • Traditional wood veneer cabinet with deluxe wood tambour

  • Available in light, medium and dark oak veneer

  • Tab stop controls

  • Record/playback with STOP, PLAY, REC pistons

  • USB-enabled for unlimited storage of registration data and saved performances

  • Hymn Player automatically plays 350 built-in hymns with introduction & verse or Prelude mode

  • Bench in matching finish

  • Rolltop + lock

  • 32-note radiating AGO pedalboard velocity-sensitive for orchestral voices

  • Self-contained pedalboard mechanism for great reliability on uneven flooring or carpeting

  • Kick switch programmable as Off, Next, Prev, Sustain and Gospel Rotor for orchestral voices

  • Programmable pedal F# sustain function for orchestral voices

  • Memory +/- pistons

  • 9 historic temperaments

  • Tuning control

  • -6/+5 transposer

  • True Sound Space: 12 real reverb environments

  • Stereo headphone jack

  • 2 x 1/4" Line Inputs

  • 2 x 1/4" Line Outputs

  • MIDI In and Out Connections

  • 2.1-channel internal audio system: 2 channels x 50 watts fullrange audio + 1 channel x 160 watts subwoofer

  • 5 loudspeakers using coaxials for a rich and highly defined sound

  • 8-channel external audio outputs

  • 2-channel audio system for external loudspeakers (optional)

  • Onboard voicing finishing and leveling controls

  • Internal Audio OFF, Main OFF, Antiphonal ON

  • Pipe organ modeling technologies

  • Great/Pedal Enclosed

  • Organ Type piston instantly activates American Eclectic, English Cathedral, French Romantic or German Baroque stops

  • Adjustable tremulants

Stoplist

GREAT

American Eclectic

Violone 16

Principal 8

Bourdon 8

Gamba 8

Erzähler Céleste II 8

Octave 4

Spitzflöte 4

Super Octave 2

Cornet V

Fourniture IV

Trumpet 8

Great Orch A

Great Orch B

Tremulant

Swell to Great

Choir to Great

English Cathedral

Open Diapason 16

Open Diapason 8

Chimney Flute 8

Second Diapason 8

Salicional 8

Principal 4

Waldflute 4

Fifteenth 2

Cornet IV

Mixture IV

Tromba 8

French Romantic

Montre 16

Montre 8

Bourdon 8

Flûte Harmonique 8

Gamba 8

Prestant 4

Flûte Ouverte 4

Doublette 2

Cornet IV

Fourniture IV

Trompette 8

German Baroque

Prinzipal 16

Prinzipal 8

Rohrflöte 8

Quintatön 8

Salicional 8

Oktave 4

Gemshorn 4

Super Oktave 2

Kornett V

Mixtur VI

Trompete 8

Variant Library

Quintaton 16

Diapason 8

Clarabel Flute 8

Doppel Flute 8

Voix des Anges II 8

Harmonic Flute 4

Quint 2-2/3

Harmonic Piccolo 2

Terz 1-3/5

Cymbel III

French Horn 8

SWELL

American Eclectic

Bourdon Doux 16

Diapason 8

Viola Céleste II 8

Octave 4

Flute Traverse 4

Nazard 2-2/3

Block Flute 2

Tierce 1-3/5

Plein Jeu IV

Double Trumpet 16

Trumpet 8

Oboe 8

Swell Orch A

Swell Orch B

Tremulant

English Cathedral

Bourdon 16

Horn Diapason 8

Stopped Diapason 8

Viole Céleste II 8

Octave Gamba 4

Flute 4

Quintflute 2-2/3

Lieblich Piccolo 2

Seventeenth 1-3/5

Mixture III

Trombone 16

Trumpet 8

Cornopean 8

French Romantic

Dulciane 16

Montre 8

Bourdon 8

Viola Céleste II 8

Prestant 4

Flûte Octaviante 4

Nasard 2-2/3

Octavin 2

Tierce 1-3/5

Plein Jeu III

Bombarde 16

Trompette 8

Hautbois 8

German Baroque

Lieblich Gedackt 16

Prinzipal 8

Holzgedackt 8

Gamba 8

Oktave 4

Flöte 4

Nasard 3

Waldflöte 2

Quinte 1-1/3

Scharff IV

Posaune 16

Trompete 8

Dulzian 8

Variant Library

Violon 16

Geigen Principal 8

Harmonic Flute 8

Flute Céleste II 8

Fugara 4

Rohrflute 4

Sesquialtera II

Italian Principal 2

Sifflöte 1

Ripieno IV

Basson 16

Basson 8

Vox Humana 8

CHOIR

American Eclectic

Principal 8

Gedackt 8

Unda Maris II 8

Octave 4

Koppelflöte 4

Spitzflöte 2

Larigot 1-1/3

Scharff III

Clarinet 8

Festival Trumpet 8

Choir Orch A

Choir Orch B

Swell to Choir

Tremulant

English Cathedral

Diapason 8

Concert Flute 8

Gemshorn Céleste II 8

Principal 4

Orchestral Flute 4

Nachthorn 2

Nineteenth 1-1/3

Mixture III

English Horn 8

Royal Tuba 8

French Romantic

Montre 8

Bourdon 8

Viola Céleste II 8

Prestant 4

Nachthorn 4

Piccolo 2

Quinte 1-1/3

Cymbel III

Cromorne 8

Trompette en Chamade 8

German Baroque

Spitz Prinzipal 8

Gedackt 8

Spitzgamba 8

Oktav 4

Blockflöte 4

Gemshorn 2

Sifflöte 1

Mixtur III

Krummhorn 8

Schalmey 8

Variant Library

Bach Principal 8

Gross Flute 8

Viola Pomposa 8

Musette 4

Unda Maris II 4

Doublette 2

Sept-Terz II

Sesquialter II

Bombarde 8

Corno di Bassetto 16

PEDAL

American Eclectic

Contra Bourdon 32

Principal 16

Subbass 16

Octave 8

Bass Flute 8

Choral Bass 4

Mixture III

Bombarde 16

Trumpet 8

Pedal Orch A

Pedal Orch B

Great to Pedal

Swell to Pedal

Choir to Pedal

English Cathedral

Dbl. Open Diapason 32

Open Diapason 16

Bourdon 16

Diapason 8

Flute 8

Fifteenth 4

Mixture III

Trombone 16

Tromba 8

French Romantic

Contra Violon 32

Contrebasse 16

Soubasse 16

Montre 8

Bourdon 8

Prestant 4

Plein Jeu III

Bombarde 16

Trompette 8

German Baroque

Untersatz 32

Prinzipalbass 16

Bordun 16

Oktave 8

Gedeckt Bass 8

Oktave 4

Hintersatz III

Posaune 16

Trompete 8

Variant Library

Open Wood 32

Violone 16

Bourdon Doux 16

Violoncello 8

Lieblich Bourdon 8

Nachthorn 4

Clairon 4

Bass Clarinet 16

Trombone 8

Library

Inspire Series 343

18 BUILT-IN ORCHESTRAL VOICES:

Orchestral voices are accessed through

any of the eight Orchestral Couplers.

• Piano

• Elect. Piano

• Harp

• Harpsichord

• Celesta

• Strings

• Slow Strings

• Choir Oohs

• Choir Aahs

• Gospel Organ I

• Gospel Organ II

• Flute

• Trumpet

• Oboe

• Clarinet

• Handbells

• Timpani

• Chimes
